H-Max™ – 8cu ft. skip/bucket
The H-Max is an engine-powered machine with Hydraulic Tipping, making it much easier to empty the skip.
It can carry 800lbs/365kg/8cu ft and will climb a 30º slope fully loaded.
The machine is fitted with the Honda GXV Commercial grade 5.5hp engine and the transmission drive axle has 3 forward and 1 reverse gears – the same engine and transmission as Muck-Truck® and Max-Truck™ as they has been tried and tested for over 30 years.
£3,003.00 (excl. VAT)
UK Mainland Only
Hydraulic tipping technology makes tipping easier: just push the lever forward
Built with extra reinforcement metalwork – sturdier/stronger for the extra load
Balanced weight distribution and longer handles for steering as easy as the rest of the Muck-Truck® range.
Measures 29″ (736mm) in width, 72″ (1828mm) in length for easy onsite access.
All the metal work is laser cut and powder coated for a perfect finish
Specifications
Model: H-Max™
Engine: Honda GXV 160 Commercial 5.5hp
Transmission: 3 forward / 1 reverse
Speed: 0-3.5mph
Fuel: Unleaded Petrol
Capacity: 8cu/ft – 800lbs/365kg carrying capacity
Noise Rating: Up to 98db
Parking Brake: Disc
Wheels: 4 x 400×10, 4 ply tractive
Dimensions: (L) 72″ x (W) 29″ x (H) 42″ / (L) 1828mm x (W) 736mm x (H) 1066mm
Weight: Unladen 407lbs./185kg
Traction: 4 Wheel drive
The H-Max™ can carry 800lbs/365kg/8cu ft and will climb a 30º slope fully loaded. The machine is fitted with the Honda GXV Commercial grade 5.5hp engine. The transmission drive axle has 3 forward and 1 reverse gears. Yes, the H-Max™ is being run with the same engine and transmission as Muck-Truck® and Max-Truck®, as it has been tried and tested for over 30 years.
What makes the H-Max™ special is the Hydraulic tipping technology that makes tipping easier, just pushing the hydraulic lever forward. Balanced weight distribution and longer handles allow the steering to be as easy as the rest of the Muck-Truck® range.
Learn more about Muck-Truck®’s full range of accessories.
Muck-Truck Warranty
Muck-truck Warranty begins with the date of Purchase. The Sales Invoice or other Proof of Purchase will validate the Warranty start date. When Proof of Purchase or Ownership is not available, the Machine Serial Number will be used to determine the manufacturing date of the product.
Please download the warranty claim form and once the form is completed, please send it to admin@mucktruck.com for approval.
Product Video
